Tycon Systems TP-DC-1256GD-BT
Tycon Systems
Article code TP-DC-1256GD-BT
{{ fullProductName }}
10 / 60V DC PoE injector with 70W PoE budget Midspan,12V PoE, 24V PoE, support bt standard 802.3bt Class 8
Description Tycon Systems TP-DC-1256GD-BT
The 5 Gigabit compatible TP-DC-1256GD-BT are very high power DC to DC converters / PoE inserters designed for the latest 802.3bt PoE standard. The unique PoE inserter supplies 56VDC Class 8 802.3bt PoE power on all 8 Ethernet wires (4 Pair). They support data throughput rates to 5Gigabit. They are backward compatible with 802.3at devices.
Key features:
- Input Voltage 10VDC to 60VDC
- 8 wire (4 Pair) 56VDC 802.3bt PoE Output
- High Power Output to 70W
- Dual DC Inputs for Connecting 2 Power Sources
- 5 Gigabit Data Throughput
- Low Voltage Disconnect Feature
- Short Circuit, Over Current and Reverse/Over Voltage Protection
- Industrial Temperature Range to 70C
Specifications
Product
| Model number | TP-DC-1256GD-BT |
| Brand | Tycon Systems |
| Category |
Other Products
Switches, PoE & power supply
|
| HS Code |
850440
|
| Weight |
1000 grams
|
|
Switches/PoE/voeding
|
PoE Midspan
|
