Hanwha SLM-5M16

SLM-5M16 – 16mm C-mount Lens for Mono BCR Cameras

The SLM-5M16 is a 16mm C-mount lens designed for Mono BCR cameras, supporting the TNS-7000M. It is built for CMOS imaging devices with a sensor size range of 1/3.1" to 1/1.8" and delivers resolution from 3M to 5M. With a maximum aperture of F6 and a focal length of 16mm, it provides a horizontal angular field of view of 16.4° to 23.7°, a vertical field of view of 12.3° to 19.9°, and a diagonal field of view of 20.4° to 30.6°. The lens has a back focal length of 9.97mm and a flange back focal length of 17.526mm. It is rated for operation in temperatures from -20°C to +60°C (-4°F to +140°F).

Key Features:

• 16mm focal length
• C mount
• Resolution: 3M~5M
• Max. Aperture F6
• Supports TNS-7000M
• Operating temperature -20°C~+60°C
