Hanwha SLA-2M2400P

SLA-2M2400P: 2.4mm Fixed Lens Module for PNM-9320VQP

The SLA-2M2400P is an exchangeable 2.4mm fixed focal lens module designed for the PNM-9320VQP camera. It uses a 1/2.8" 2MP CMOS imaging device with a resolution of 1945(H) x 1109(V), delivering a wide angular field of view of H:135.4˚, V:71.2˚, D:161.6˚. With a maximum aperture of F2.0, it achieves a minimum illumination of 0.055 Lux in both Color and B/W modes, and supports Electrical Day & Night switching. The module offers 150dB Wide Dynamic Range and a 50dB S/N ratio for clear images in challenging lighting conditions. It mounts via M12 directly to the main unit and supports Pan/Tilt/Rotate adjustment for flexible positioning.

Key Features:

• 2.4mm fixed focal lens, F2.0 max aperture
• 1/2.8" 2MP CMOS sensor, 2.16M total pixels
• 0.055Lux minimum illumination (Color/B/W)
• 150dB Wide Dynamic Range (WDR)
• Electrical Day & Night
• M12 mount, exchangeable for PNM-9320VQP
