Mobotix MX-SWITCH1

MOBOTIXs new MxSwitch is a compact DIN rail module that can be used to directly connect and power up to four MOBOTIX through Stations, cameras or other PoE / PoE devices. In addition to the four PoE ports with a total maximum power of 75 watts and the uplink port without PoE power, MxSwitch also offers technical possibilities to make connecting and feeding a complete MOBOTIX by Station particularly easy. Thanks to the integrated MxSplit technology, four of the eight wires (or two of the four cable pairs) of the Ethernet cable of a door station can be used, for example:

- as a two-wire connection cable for the electromagnetic anti-theft protection module in the outdoor station frame; and

- as a two-wire connection cable for the MxBus, for example to connect the MX-DoorMaster or an MX-GPS-Box directly to the MxSwitch.

Example: Twe DoorStations, An M15, An MxDisplay +

PoE power supply for all devices on ports A to D. By stations connected to ports A and D. M15 and MxDisplay connected to ports B and C (PoE only). Bridge 1 (B1) on MxSwitch connects pushbutton button for theft protection to wire pair 7/8 of ports A and D. Bridge 2 (B2) on MxSwitch connects 12 V DC to wire pair 4/5 of ports A and D. Connect wire pair 7 / 8 of the network cable of the installation with theft protection of the door frames. Connect wire pair 4/5 of the network installation cable to signal output from the BellRFID and KeypadRFID respectively. Connect the signal outputs of the BellRFID and the KeypadRFID to the door opener of the corresponding door.

Required accessory (not included): External power supply 48 V DC (output current min. 2 A)
