Hanwha ANO-L7012R
Hanwha
Article code ANO-L7012R

Outdoor Bullet 4MP camera, 30fps, IR, fixed lens 3mm 98.3°
- Outdoor 4MP Bullet camera
- Lens 98.3°
- Light sensitivity color: 0.1lx B/W: 0lx (IR LED on)
Description Hanwha ANO-L7012R
Wisenet A Series bullet camera, 4MP @ 30 FPS, 3mm fixed focal lens, WiseStream II, triple codec (H.265/H.264/MJPEG),120dB WDR, IR LEDs 20m(65.62ft), day & night (ICR), FoV H: 98.3° / V: 54.2°, virtual area (intrusion/enter/exit), virtual Line (crossing/ direction), motion detection, tampering, hallway view, SD card, IP66, PoE, white.
Key Features
- 4 MP resolution, up to 30 fps (H.265/H.264)
- Color: 0.1Lux (F1.6, 1/30sec), B/W: 0Lux (IR LED on)
- 3mm lens with 98.3° HFoV
- Visible IR length: 20 m
- Day and night (ICR), WDR (120dB)
- H.265, H.264, MJPEG, multiple streaming supported
- Blur detection, direction detection, motion detection, tampering
- (90⁰/270⁰), LDC support, WiseStream II
- Micro SD/SDHC/SDXC memory slot (max. 128 GB)
- IP66 support
Downloads
Datasheet | Download |
User manual | Download |
Installation manual | Download |
Product dimensions | Download |
Specifications
Product
Model number | ANO-L7012R |
GTIN code | 8801089228604 |
Brand | Hanwha |
Category |
IP Cameras
Bullet
|
HS Code |
852589
|
Country of origin |
Vietnam
|
Weight |
390 grams
|
Size (lxwxh) |
298
x 497 x 241 millimeters
|
Camera Properties
|
Outdoor
Built-in infrared
|
Basic Functionality
|
Day and night
Local Storage
|
Resolution
|
4MP
|
Hanwha Series
|
Wisenet A
|
Angle of View
|
91° - 100°
|
Encoding
|
H264
H265
MJPEG
|
