Veracity VHW-HWPS-B8

8 Channels per HIGHWIRE Powerstar Base 8 unit, up to 32ch in 1U

Four 8-channel Base units provide 32 IP channels in 1U, with space for an optional 1U power supply and up to 25W POE per channel. The HIGHWIRE Powerstar product family offers high-speed Ethernet,
reliable power delivery and long range even over low-grade coaxial
cable. The HIGHWIRE Powerstar Base 8 is available in an integrated 8-channel modular unit for rack mounting, giving up to 32 channels in 1U, with space for an optional rear-mounted 1U PSU.

Key Features:

• 8 channels per Base unit, up to 32 channels in 1U
• Full duplex 100Base-TX performance on each coax link
• Gigabit uplink port with fibre option via SFP socket
• Only 1 main switch port required per 8 channels
• POE or POE Plus per channel, on all channels
• Up to 300m on RG59, 400m on RG6, 500m on RG11
• Automatic configuration for simple installation
