AXIS Power Supply Din PS56 240W
AXIS
Article code 01726-001
{{ fullProductName }}
Axis DIN PS56 240 W network switch component Power supply
Description AXIS Power Supply Din PS56 240W
Specifications:
Power supply for AXIS T8504-R Industrial PoE Switch. 240W 56V 5A for DIN rail mounting. Industrial power supply with a compact design, 100-240 V AC input voltage and delivers 240W. Dimensions: W: 60 mm (2.4 in) H: 130 mm (5.1 in) D: 125 mm (4.9 in) Weight 1050 g (2.3 lb) Operating conditions: -25 ° C to 70 ° C (-13 ° F to 158 ° F)
Import:
- AC power consumption 1.5A @ 230V AC / 3A @ 115V AC
- AC input voltage range 85-277V AC (Derating @ 100V AC)
- DC power consumption 1.5A @ 370V DC / 3A @ 120V DC
- DC input voltage range 80-370V DC
- Input frequency 45-65Hz
- Nominal input voltage 100-240V AC (wide range input)
Output:
- Output power 240W
- Output voltage 56V DC
- Output voltage 30-56V (adjustable via potentiometer)
Compatible products
Switches, PoE & power supply
Specifications
Product
| Model number | 01726-001 |
| GTIN code | 7331021066991 |
| Brand | AXIS |
| Category |
Other Products
Switches, PoE & power supply
|
| HS Code |
850440
|
| Country of origin |
China
|
| Weight |
1230 grams
|
| Size (lxwxh) |
193
x 104 x 250 millimeters
|
|
