Mobotix Mx-NPA-UPoE1A-60W

Mx-NPA-UPoE1A-60W: UPoE 60W Network Power Injector

The Mx-NPA-UPoE1A-60W is a UPoE (PoE++) network power injector that delivers up to 60W of output power over 4-pairs. It is IEEE 802.3at compliant with 2-event classification and backward compatible with IEEE 802.3af, making it suitable for a wide range of powered devices. The injector supports 10/100/1000Base-T applications and operates from an AC input of 100 to 240 VAC (50 to 60Hz) with a current draw of 1.5A. It offers plug-and-play installation for quick setup without additional configuration.

Key Features:

• 60W output power over 4-pairs
• IEEE 802.3at compliant with 2-event classification
• IEEE 802.3af backward compatible
• Supports 10/100/1000Base-T applications
• AC input: 100-240 VAC (50-60Hz), 1.5A
• Plug-and-play installation
