Engenius ECB-600

The ECB600 is a wireless 11n 600Mbps (300Mbps + 300Mbps) dual band

competitor Access Point / Client Bridge. This makes it possible

work simultaneously with 2.4GHz and 5GHz.

You can optimally enjoy surfing through the media optimization of

the ECB600. The access point is equipped with an MSSID + VLAN around your

data more secure. And is equipped with PoE as standard

interoperable with 802.3at / af, for a flexible internet connection.

The ECB600 is equipped with 4 antennas with a wide range in all sorts

circumstances and the elegant design is an addition for everyone

workplace.

• Applications EnGenius ECB600
• Access Point
• Client Bridge
• Client Router
• WDS Access Point
• WDS Bridge
• WDS Station
• Universal Repeater

Key features EnGenius ECB600

• Provides support for up to 100 clients
• IEEE 802.11a / b / g / n
• Wireless-N transfer speed of 600 Mbps (300 + 300)
• PoE IEEE 802.3at / af Complaint (12V / 2A DC Supported)
• Transmitting power of max 29dB (2.4GHz) / 26dB (5GHz)
• External 4x5dBi antenna
• Security via WEP, WPA or WPA2

Power over ethernet

It is also possible to use a PoE adapter, such as the Axis T8133. Power over ethernet over a distance of 100 meters. The Axis T8133 delivers a power of 30W over a distance of up to 100 meters. The compact device is very easy to install.

Package Content

• ECB600 Access Point / Client Bridge
• 12V / 2A 100V ~ 240V Power Adapter
• RJ-45 Ethernet LAN cable
• 2.4 GHz Detachable antennas (2x)
• 5 GHz Detachable antennas (2x)
• Wall mounting kit
• CD-ROM with user manual
• Quick user guide (Quick Installation Guide)
