Hanwha TNB-6030
Hanwha
Article code TNB-6030
{{ fullProductName }}
End-of-life: Product might no longer be available
Public View Monitoring Camera 2MP, 4.6mm, 73.8°, 60fps, 1920x1080 Resolution
Would you like personal advice on alternatives?
Description Hanwha TNB-6030
PVM camera powered by Wisenet 5, 1080p (1920x1080), micro HDMI output, 16:9 aspect ratio, face detection display for visual deterrent, customizable text overlay, 4.6mm fixed lens(73.8°H), 150dB WDR, H.265/H.264/MJPEG, WiseStream II compression technology, micro SD/SDHC/SDXC, bi-directional audio, hallway view mode
Key features:
- 2 Megapixel (1920 x 1080) resolution
- microHDMI video Output (1080p Full HD)
- True WDR (150dB)
- Face detection overlay
- Text overlay and blinking "Recording in progress"
- Discreet design for public view monitoring
- 60fps@all resolutions, 0.06 Lux@F2.5 (Color)
- H.265, H.264, MJPEG codec supported, Multiple streaming
- SD/SDHC/SDXC memory slot (256GB)
- Hallway view, WiseStream II , LDC support
- Bi-directional audio support, Alarm I/O (1ea)
- PoE, 12V DC
- To be mounted with the SBP-300NM, not included
Downloads
| User manual | Download |
Specifications
Product
| Model number | TNB-6030 |
| GTIN code | 8801089106872 |
| Brand | Hanwha |
| Category |
IP Cameras
Box
|
| HS Code |
852589
|
| Weight |
245 grams
|
| Size (lxwxh) |
286
x 466 x 277 millimeters
|
|
Resolution
|
1080p (2MP)
|
|
Hanwha Series
|
Wisenet T
|
|
Encoding
|
H264
H265
MJPEG
|
|
Thermal camera properties
|
≥ 30 fps
|
| Date published | 11/11/2025 |
