Hanwha PNM-C12083RVD

Hanwha Article code PNM-C12083RVD

NetcamCenter {{ fullProductName }}

Outdoor 2×6MP AI Multi-Directional Camera, 2 zoom camera's, 3.54 ~ 6.69mm, 15fps, IR leds, H.265
Product variants
In stock
Buy now
+ Quote
  • Outdoor 2×6MP AI Multi-Directional Camera
  • Zoom range per lens 95.08° ~ 47.64°
  • Light sensitivity Color: 0.16 Lux, B/W; 0.016 Lux, 0 Lux (IR Led On)
  • 360° degrees IR-lights

Description Hanwha PNM-C12083RVD

Key benefits:

  • Capture two scenes with one multidirectional camera and individual FoV settings with position adjustable varifocal lenses
  • Licence-free analytics based on AI object classification reduces false alarms and improving search results
  • Bandwidth and image optimisation with AI based features WiseStreamⅢ, prefer shutter control and noise reduction
  • Reduce installation and network infrastructure costs by replacing multiple cameras with one multidirectional camera
  • Save on VMS licences, Wisenet WAVE and other leading VMS’s, only requires one channel
  • Excellent image quality in low-light conditions with 360 degree IR illumination
  • No compromise on cybersecurity thanks to Secure by Default certification, TPM 2.0 (FIPS 140-2) and NDAA Compliance
  • Robust and durable in any weather with IP66, IK10 and NEMA4X certifications
  • Installation aids such as Wi-Fi dongle (optional) and CVBS video output

Key features:

  • Analytics based on AI object classification; Person Face, Vehicle, License plate
  • AI object attributes Car, Bus, Truck, Motorcycle, Bicycle
  • Virtual area and crossing line rules based on AI object classification
  • Defocus detection, Motion detection, Tampering, Audio detection, Sound classification
  • 360 degree IR viewable length 25m(82ft)
  • Micro SD/SDHC/SDXC 1 slot: Max. 512GB
  • Flip, Mirror, Hallway view (90°/270°) per channel
  • WiseNRⅡ, Auto prefer shutter control, WiseStreamⅢ, extremeWDR (120dB)
  • Maximum 15fps@6MP
  • 3.54~6.69mm motorized varifocal lens, 78° tilt anglel
  • Compatible with I/O ethernet box to connect alarm and audio devices
  • Includes BestShot
  • Secure by Default and TPM 2.0 (FIPS 140-2)
  • IP66, NEMA4X, IK10

Downloads

Datasheet Download pdf
User manual Download pdf
Installation manual Download pdf
Product dimensions Download pdf

Video

Specifications

Product
Model number PNM-C12083RVD
GTIN code 8801089217400
Brand Hanwha
Category
IP Cameras
Dome
Multidirectional
HS Code
852589
Country of origin
Vietnam
Weight
1500 grams
Size (lxwxh)
236 x 288 x 197 millimeters
Camera Properties
Outdoor
Built-in infrared
Vandal resistant
Basic Functionality
Day and night
Audio support
Local Storage
Resolution
5MP - 7MP
Hanwha Series
Wisenet P
Angle of View
61° - 90°
Optical zoom
1-10x
Encoding
H265
